MultiSurf gallery

Click on thumbnails to view full-size images

ZYD-Billy Joel An upscale 57' commuter style yacht, designed by Doug Zurn.
Related press release.
Luxe Motor 20m
K&S maritiem technisch bureau, Enkhuizen, Netherlands -
more info:
Diana-Yacht 44.4m ocean going motor yacht by Diana Yacht Design, Haarlem, Holland. Read more. Luxe Motor 20m The 20m "Luxe Motor" (left and above) is a traditional inland waterways barge built in large numbers during the 1920's in Holland.
Water is not the only element for exciting MultiSurf designs!
By J.C. Berland
G&W68ft Ginton & Weber Naval Architects, Haarlem, Holland
68ft power yacht, max. speed 27 knots, builder: Mulder Shipyards
Go Anywhere Details of Michael Porter's "Go Anywhere" boat - a boat "intended to allow two
middle-aged people to live and work almost anywhere one can go by water." More details on Michael's website.
G&W88ft Ginton & Weber,
88ft power yacht, max. speed 25 knots, builder: Mulder Shipyards
More info:
Go Anywhere - frames
Frames - an example of MultiSurf components (model by John Letcher) Acadia46 Acadia46, Design: Geoffrey Dickes
Builder: Eric Clark, Marine Systems Inc. More info:

NEW  29z by Doug Zurn


In Doug's words: "Some shots of the latest, designed entirely in Multisurf (Hull; deck; windscreen; grid and liner)."
Please note: All rights of designs on this page are reserved. The use of these designs, directly or  indirectly, for any work other than that authorized is forbidden and will be considered an infringement of these rights.
